EMF tester PCE-EMF 20
Views: 146
Description
The EMF tester is a device for measuring electric and magnetic fields simultaneously. Ideal for home use to check routers, Bluetooth devices, radios, televisions, computers, printers, microwaves, refrigerators and cell towers. It offers a measuring range of 1 to 1999 V/m for electric fields and 0.01 to 99.99 µT for magnetic fields. The EMF tester has an alarm threshold of 40 V/m or 4 µT, which automatically triggers an acoustic alarm if exceeded.
The EMF tester works in a bandwidth of 5 Hz to 3500 MHz and takes less than a second to deliver a measurement result. A built-in 700 mAh lithium battery with USB-C interface makes the device comfortable and durable. An LED display enables a clear display of the measured values and the compact design with just one button ensures easy handling. In addition, the EMF tester automatically switches off when inactive to save energy.
Characteristics
Specification
| radiation | |
| measuring range | 1 … 1999 V/m |
| resolution | 1 V/m |
| accuracy | 1 V/m |
| radiation | |
| measuring range | 0.01 … 99.99 µT |
| resolution | 0.01 µT |
| accuracy | 0.01 µT |
| General technical data | |
| display type | LED |
| display size | 2.2 inches |
| interface | USB-C |
| response time | 0.5 s |
| Automatic shutdown | 5 minutes |
| Bandwidth MF of | 5 Hz |
| Bandwidth MF to | 3500 MHz |
| Bandwidth EF of | 5 Hz |
| Bandwidth EF to | 3500 MHz |
| alarm | acoustically, optically |
| menu language | English (US), English (GB) |
| protection class (device) | IP20 |
| power supply | 5 V |
| Weight | 75 g |
| operating conditions | 0 … 50 °C, 0 … 90% r. F |
| storage conditions | 0 … 50 °C, 0 … 90% r. F |
| battery | 1 x 3.7 V SL 603040, lithium-ion battery |
| capacity | 700 mAh |
| Dimensions (L x W x H) | 110 x 55 x 23 mm |
