Microohm-Meter PCE-MO 3001
Views: 2118
$0.00
Description
PCE MO 3001
meter for the smallest resistances / 0.1 μΩ resolution / accumulator
operated /
extensive
LCD /
polycarbonate ABS casing /
EN 61010-1
The
microohm meter PCE-MO 3001 is made to measure smallest electrical
resistances. It uses four test cables that can be connected to the
microohm meter. The microohm meter uses two test cables and a constant
current source to allow stable current to flow within the measured
device. The other two test cables measure the voltage drop. Due to the
fact that this microohm meter is able to measure six different
measurement ranges with three different measured currents, the user has
the chance to observe a wide range of current.
The
microohm meter is mostly used in those fields where resistance need to
be estimated. Because of the measured current which can be set up to 1
A, also the smallest resistances can be measured. The wide LCD and large
buttons of this microohm meter allow a comfortable use.
Resolution
of up to 1µΩ
– Internal temperature surveillance
– Large LCD
USB-interface
– Robust plastic case
– Internal accumulator
Specification
| Technical specifications of the microohm meter |
|||
| Measurement range / resolution / accuracy |
2,000 mΩ / 1 µΩ / ± (5 % + 5 digits) 20,00 mΩ / 10 µΩ / ± (4 % + 4 digits) 200,0 mΩ / 100 µΩ / ± (4 % + 4 digits) 2000 mΩ / 1 mΩ / ± (3 % + 4 digits) 20,00 Ω / 10 mΩ / ± (2 % + 4 digits) 200,0 Ω / 100 mΩ / ± (2 % + 4 digits) |
||
| Test current |
10 mA (200 Ω area) 100 mA (20 Ω, 2 Ω areas) 1 A (200 mΩ, 20 mΩ, 2 mΩ areas) |
||
| Test current accuracy |
10 mA ±1.5 % 100 mA ±2.0 % 1 A ± 3.0 % |
||
| Max. output voltage |
0 V rms |
||
| Power supply |
internal accumulator |
||
| Casing | Polycarbonate, ABS |
||
| Weight | 3.8 kg | ||
| Dimensions | 330 x 260 x 160 mm | ||
| Norm | EN 61010-1 |
||
Delivery Scope
content
of the microohm meter
x Microohm Meter PCE-MO 3001, 1 x test cable set, 1 x power cable, 1 x
user manual, 1 x carrier bag
